NNER TRIM

MRXA <u> </u>

• 1. PREPARE DOOR CUTOUT PER TEMPLATE
• 2, INSTALL MORTISE INTO THE PREPARED DOOR (SEE MORTISE INSTRUCTIONS).
• 3. INSTALL SPINDLES IN MORTISE, NOTE: SPRING FACES OUT, SEE ORIENTATION ON EXPLODED VIEW.
• 4. SLIDE INSIDE PADDLE ASSEMBLY ONTO THE MORTISE WITH POSTS GOING THROUGH THE MORTISE THROUGH HOLES WITH THE SPINDLE ENGAGING THE CAM ON THE I/S ASSY.
• 5. ON THE OUTSIDE— POSITION THE OUTSIDE MOUNTING PLATE AND PUT THE 2 PLATE MOUNTING SCREWS THROUGH HOLES ON THE OUTSIDE MOUNTING PLATE, ALIGN THE SCREWS WITH THE POSTS AND TIGHTEN.
• 6. POSITION THE OUTSIDE PADDLE ASSEMBLY OVER THE OUTSIDE MOUNTING PLATE WITH THE SPINDLE ENGAGING THE CAM ON THE O/S PADDLE ASSEMBLY. USE THE 3 PADDLE ASSY MOUNTING SCREWS TO SECURE THE ASSEMBLY.
• NOTE: ONCE THE PADDLE ASSEMBLY IS SET ON BOTH SIDES—SLIDE THE PADDLE (DOWN) ON BOTH SIDES TO ENSURE THE MORTISE LATCH RETRACTS AND THERE IS NO BINDING, IF THE LATCH OR PADDLE BINDS REMOVE THE PADDLE ASSEMBLY FROM THE MOUNTING SCREW SIDE AND LOOSEN THE MOUNTING SCREWS AND ALIGN THE OUTSIDE MOUNTING PLATE AND THE INSIDE PADDLE ASSY WITH THE CENTER OF THE MORTISE HUBS AS MUCH AS POSSIBLE UNTIL NO BINDING OCCURS, TIGHTEN THE SCREWS AND RETRY.
• 7. OPTIONAL- INSTALL CYLINDER (COLLAR, WAVE WASHER, CYLINDER) AND SECURE WITH SET SCREW (UNDER MORTISE FACE PLATE). INSTALL THUMBTURN.
• 8. CHECK LOCK DOOR. FOR CORRECT OPERATION BEFORE CLOSING THE

DATE: 7/24/13	DRAWN BY:	SPECIFIED:	DTHERWISE	DRAFT
				⊅
MACHINED SURFACES 125√ :	FRACTIONS = ±.8 ANGLES = ±1/2* © .12	X.X (METRIC) =±0.4	SPECIFIED:	TOLERANCES
PART#: MRXA MTG INSTR	TITLE: MRXA HORIZONTAL MOUNTING INSTRUCTIONS	FINISH: N/A	HEAT TREAT: N/A	MATERIAL: N/A

THIRD ANGLE

PADDLE ASSY MOUNTING SCREW

PADDLE ASSY MOUNTING SCREWS

FIG 2 IN BOTH HOLES IN THE THUMB TURN, PLACE A 5/64TH ALLEN WRENCH (PROVIDED) THROUGH THE HOLE IN THE SET SCREW IN THE INNER PLATE AND SECURE THE THUMB TURN BY TURNING COUNTER-CLOCKWISE (TO REMOVED ROTATE CLOCKWISE).

OTATE CLOCKWISE).

TURN COUNTER-CLOCKWISE TO TIGHTEN

EXTLUDED VIEW

RE/

DESCRIPTION

DATE

ALIGN INNER PLATE

HOSPITAL THUMB TURN INSTRUCTIONS

• 1. PREPARE DOOR PER TEMPLATE.
• 2. USE THE GUIDE PIN TO HELP ALIGN THE INNER PLATE, MATCH DRILL (OR MARK LOCATION AND DRILL) THE 4 HOLES TO MOUNT THE INNER PLATE, PILOT HOLE SIZE FOR #6 SCREW IN A WOOD DOOR IS $\backslash frac\{\backslash pi\}\{6\}$ .
• 3. MOUNT THE INNER PLATE WITH THE 4 SCREWS.
• 4. INSTALL THE SPINDLE AND THUMB TURN (SEE EXPLODED VIEW).
• 5. OPERATE THE LOCK TO ENSURE PROPER INSTALLATION AND ALIGNMENT.
• 6. TIGHTEN THE THUMB TURN ONTO THE INNER PLATE- SEE FIG 1 & 2. INSERT THE ALLEN WRENCH THROUGH EACH HOLE (2 IN EACH INNER PLATE) TO ENGAGE THE SET SCREW AND SECURE THE THUMB TURN ASSEMBLY, ROTATE COUNTERCLOCKWISE TO TIGHTEN IN THE ASSEMBLY AND ROTATE CLOCKWISE TO LOOSEN, SEE FIG 1 & 2.
• 7. CHECK LOCK FOR CORRECT OPERATION BEFORE CLOSING THE DOOR.

707 N.	$T\; \backslash circ\; W$
BARRANCA	nste
AVE	$\backslash bigcirc$
#

COV	707
VINA.	Z
, CALIF 91723	BARRANCA AVE #6

10/7/11	DATE:		SC	DRAWN BY:		1° MAX	SPECIFIED:	UNLESS	DRAFT
								t	IJ
⊕∰ THIRD ANGLE	MACHINED SURFACES 125/	O .12	ANGLES = $\backslash pm\; 1/2^\{\backslash bullet\}$	FRACTIONS = ±.8	X.XX (METRIC) =±0.15	X.X (METRIC) =±0.4	SPECIFIED	UNLESS OTHERWISE	TOLERANCES
ADA-TTURN	PART#;	ASSY INSTRUCTIONS	AUA IHUMB IUKN	)		FINISH 32D	HEAT TREAT: NA		MATERIAL: NOTED

THIS DRAWING AND THE INFORMATION CONTAINED THEREON OR DERIVED THEREFROM ARE THE CONFIDENTIAL PROPERTY OF TOWNSTEEL, INC. IT IS NOT TO BE REPRODUCED, OR DISCLOSED TO OTHERS, AND MAY BE USED ONLY FOR THE PURPOSE OF ENABLING THE PARTY TO WHOM IT HAS BEEN LOANED TO QUOTE ON OR FILL AN ORDER FOR TOWNSTEEL, INC., OR AS MAY BE OTHERWISE AUTHORIZED BY TOWNSTEEL, INC. IN WRITING.

INSTALLATION GUIDE FOR ELECTRIFIED MORTISES- SOLENDID ONLY

INSTRUCTIONS

• 1. PREPARE MORTISE POCKET IN DOOR PER TEMPLATE, ACCESS FOR THE WIRING TO BE PER INSTALLERS REQUIREMENTS, IT IS RECOMMENDED THAT AN ACCESS CHANNEL IS BORED TO PROVIDE CONTACT FROM THE ELECTRIC TRANSFER HINGE OR OTHER MEANS OF TRANSFER TO THE MORTISE POCKET.
• 2. CONNECT WIRES AS NECESSARY AND SLIP THE MORTISE INTO THE PREPARED POCKET IN THE DOOR, TAKE CARE TO ENSURE WIRES ARE NOT PINCHED OR DAMAGED, NOTE: IT IS RECOMMENDED THAT ALL WIRING BE DONE BY A LICENSED ELECTRICIAN FAMILIAR WITH THE SUPPORTING EQUIPMENT.
• 3, ALWAYS ENSURE DOOR OPERATES PROPERLY BEFORE LOCKING.

SPECIFICATIONS:

SOLENDID (SPECIFIED BY MODEL NUMBER):

24VDC 114.7+10%-0 Ω WIRE SIZE 24AWG

TERMS

<u>EAIL SECURE</u>- DUTER TRIM IS UNLOCKED WHEN POWER IS APPLIED. WHEN POWER IS REMOVED THE DUTER TRIM REMAINS LOCKED.

$\{\backslash tilde\; \{\backslash rm\; FAIL\}\}$ SAFE- DUTER TRIM IS LOCKED WHEN POWER IS APPLIED. WHEN POWER IS REMOVED THE DUTER TRIM REMAINS UNLOCKED,
