SIZE OPTIONS
|
Hinge Size
(inches) |
Hinge Size
(mm) |
Gauge of
Metal |
Hole
Count |
Screw Size
(Machine) |
Screw Size
(Wood) |
|---|---|---|---|---|---|
| 3 1/2 x 5 | 89 x 127 | 0.119 | 6 | 1/2 x 10-24 | 1 x 9 |
| 3 1/2 x 6 | 89 x 152 | 0.119 | 6 | 1/2 x 10-24 | 1 x 9 |
| 4 x 5 | 102 x 127 | 0.129 | 8 | 1/2 x 12-24 | 1 1/4 x 12 |
| 4 1/2 x 5 | 114 x 127 | 0.134 | 8 | 1/2 x 12-24 | 1 1/4 x 12 |
| 4 1/2 x 6 | 114 x 152 | 0.134 | 8 | 1/2 x 12-24 | 1 1/4 x 12 |
| 4 1/2 x 7 | 114 x 178 | 0.134 | 8 | 1/2 x 12-24 | 1 1/4 x 12 |
| 4 1/2 x 8 | 114 x 203 | 0.134 | 8 | 1/2 x 12-24 | 1 1/4 x 12 |
| 4 x 6 | 102 x 152 | 0.129 | 8 | 1/2 x 12-24 | 1 1/4 x 12 |
| 4 x 7 | 102 x 178 | 0.129 | 8 | 1/2 x 12-24 | 1 1/4 x 12 |
| 5 x 6 | 127 x 152 | 0.145 | 8 | 1/2 x 12-24 | 1 1/4 x 12 |
| 5 x 7 | 127 x 178 | 0.145 | 8 | 1/2 x 12-24 | 1 1/4 x 12 |
| 5 x 8 | 127 x 203 | 0.145 | 8 | 1/2 x 12-24 | 1 1/4 x 12 |
