ASSA ABLOY ACCENTRA™ Multi-Family Housing Distributor Price Book
US and Canada Prices Effective Effective March 1, 2024
Table of Contents
Distributor List Prices
| nexTouch® Cylindrical Lock Options | 4 |
|---|---|
| nexTouch® Cylindrical Lock | 5 |
|
Strikes/Latchbolts/Cylinders
|
5 |
|
Replacement Levers/Accessories/ACCENTRA module
|
6 |
| nexTouch® Sectional Mortise Lock Options | 7 |
| nexTouch® Sectional Mortise Lock | 8 |
| Replacement Levers/Strikes | 8 |
| Lock Body/Cylinders | 9 |
|
Cylinders
10 |
|
| Cylinders/Accessories/ACCENTRA module11 | |
| nexTouch® Exit Trim | 12-15 |
|
ACCENTRA Exit Devices
15 |
|
|
nexTouch® Access Control Products
16 |
|
|
nexTouch® Touchscreen Deadbolt Options
16 |
|
|
nexTouch® Touchscreen Deadbolt w/ACCENTRA
16 |
|
| nexTouch® Touchscreen Deadbolt w/ACCENTRA (cont.)17 | |
|
Strikes/Latchbolts/Cylinders
18 |
|
|
nexTouch® Interconnected Lock Options
18 |
|
|
nexTouch® Interconnected Lock
19 |
|
| Lever Designs/ACCENTRA Interconnect Lock/Strikes/Latchbolts/Cylinders | 20 |
|
Mounts Only for all Products
20 |
FREIGHT
All orders are shipped FOB factory/warehouse, except as expressly provided below. When delivered to the Transportation Company, the Purchaser assumes the risk of loss or damage in transit.
Customer orders with net product value in excess of $7,000.00 will be shipped prepaid by the ACCENTRA carrier of choice to a single destination point in the United States.
Customer orders with net product value less than $7,000.00 will be shipped prepaid by the ACCENTRA carrier of choice and freight and handling charges will be added to the customer's invoice.
A minimum freight and handling charge of $15.00 will be charged on orders with net product value of $400.00 or less. The minimum freight and handling charge will not apply to orders for only Cut (bitted) keys of any type, Master keys, Master keyed cylinders or padlocks and factory generated bitting lists that do not have any other product types included on the order. Freight on these orders will be charged as the percentage of invoice value.
For orders with net product value greater than $400.00 and less than $7,000.00, freight charges will be calculated as a percentage of the net invoice value and will be added to Customer's invoice. The percentage is based on the National U.S. Average On Highway Diesel Fuel Prices as reported by the US Department of Energy in effect at the beginning of each quarter. On the first Monday of each quarter, the new rate will be published on the ACCENTRA and Door Security Solutions extranet and will go into effect on the 2nd Monday of the quarter. Please refer to the ACCENTRA distributor
extranet for the rate chart and information on the current freight charge percentage. The percentage in effect at the time of shipment of the order will be charged.
Great Grand Master keys, Grand Master keys, Master keys, Construction Master keys, Control Keys, and Change Keys which are shipped separate from customer order for security reasons, on orders with total net product value in excess of $7,000.00 will be shipped prepaid by the ACCENTRA carrier of choice. If the total order value is less than $7,000.00, the shipping charges will be added to the Customer's invoice.
If a customer provides their own freight account number for the freight charges, ACCENTRA will apply a handling fee of $25.00 to the invoice.
Expedited shipping options – If the customer requests an expedited method of shipping such as "Next Day Air" the charges will be prepaid by ACCENTRA and the full rate of the service, as published by the carrier, will be added to the customer's invoice.
Packing – ACCENTRA will pack, mark and ship the products according to its standard procedures for shipment, unless the parties agree, in writing, that ACCENTRA will comply with any special instructions provided by the customer. Special instructions must be submitted, in writing, at time of order placement. Compliance with special instructions may result in an increased price.
Warranty
Distributor List Prices
ASSA ABLOY ACCENTRA™ (the "Company") warrants that its products sold under the ACCENTRA trade name in the United States of America & Canada are free from defects in work‑manship and materials under normal use and service.
This warranty does not cover defects or damage arising from improper installation, lack of or improper maintenance, improper storage, shipping and handling, corrosion, erosion, ordinary wear and tear, misuse, abuse, accident, unauthorized service, or use with unauthorized non-ACCENTRA products or parts. This warranty is void if any modification is made to the product, regardless of whether the modification causes or contributes to the alleged defect. All modifications are made at the risk of the party making the modification.
The only liability of the Company in tort or contract whether under this warranty or otherwise shall be limited to the repair or replacement of any product or component part which shall prove defective as covered by this warranty, within the stated time frame listed below, after delivery to the original purchaser.
Electromechanical:
All components of electromechanical products are covered by a limited warranty period of one year after invoice date thereof of the original purchaser from us.
Keying Systems:
All bittings shall be originated or authorized by the ACCENTRA Key Systems Department to be compatible with one another in a specific type of cylinder (conventional, patented, security, high security, interchangeable core) and within a particular keying system.
Warranty for Cylinders Factory or Field Combinated:
Cylinders shall be periodically lubricated depending on environmental conditions. Dry graphite, molybdenum disulfide or Polylube™ are recommended. Petroleum based liquid lubricants should only be used in cylinders in harsh or corrosive environments and should not be mixed with dry lubricants. Cylinder and/or core warranty will be voided if used in non-ACCENTRA locking devices.
Warranty for Cylinders Field Combinated:
- 1. Keys shall be cut to the ACCENTRA key bitting specifications required for the particular keyway and depth system.
- 2. All pin lengths shall be selected according to prevailing factory standards.
- 3. Original ACCENTRA cylinders and cylinder components, including pin tumblers and key blanks, shall be used. We reserve the right to void the warranty if we deem that a malfunction is a result of non-original components which do not conform to ACCENTRA standards.
| nexTouch® Cylindrical Lock |
3 year electronic and mechanical,
1 year finish |
|---|---|
|
nexTouch® Sectional
Mortise Lock |
3 year electronic and mechanical,
1 year finish |
| nexTouch® Keypad Exit Trim |
3 year electronic and mechanical,
1 year finish |
|
ACCENTRA Real Living™
Interconnected Lock |
3-year electronic and mechanical, 1-year finish |
|
ACCENTRA Real Living™ Digital
Deadbolt |
3-year electronic and mechanical, 1-year finish |
| Accessories | 1 year |
General Procedure
Product repair or replacement, or associated charges, will not be accepted under this warranty unless prior authorization from ACCENTRA has been given. Upon receipt of products returned for repair or replacement, we will determine whether products qualify for repair or replacement under this warranty. If they do not, we will obtain authorization prior to proceeding. We have no liability to pay any costs of repair performed by anyone other than qualified personnel authorized by ACCENTRA prior to the work being done.
The Company will not pay for the cost of repair performed other than in accordance with this warranty. Written notice of a product or component part believed to be defective as covered by this warranty should be sent to ASSA ABLOY ACCENTRA™, 225 Episcopal Road, Berlin, Connecticut 06037-4004, and should include your name and address, an identification of the product or component part and a brief description of the defect. Upon receipt of such notice, the Company will inform you where to ship such product or component part, shipping charges prepaid for examination and, in the event such examination reveals a defect covered by this warranty, the product will be repaired or replaced. The Company reserves the right to replace discontinued product with an equivalent product as deemed by the Company.
THIS WARRANTY IS IN LIEU OF ALL OTHER EXPRESS WARRANTIES. TO THE EXTENT PERMITTED BY LAW, ALL IMPLIED WARRANTIES ARE LIMITED TO THE DURATION OF THIS WARRANTY. ASSA ABLOY ACCENTRA™ SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS OR THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.
Returned Goods
It is the policy of ACCENTRA to not accept returns of any materials that are correctly furnished as per the Distributor's Purchase Order. Return of product due to customer order error or accommodation must be pre-arranged with ACCENTRA and approved in writing by ACCENTRA Sales Management.
No Returns accepted for the following: Specials, Anything Used, Discontinued, Modified or Damaged Product, Electrical Products, Incomplete Products (e.g. missing keys, levers, roses, etc) or 10B Finished products.
All products returned as "Goodwill" must meet the following criteria to be considered a return:
- Be in original, unmarked and undamaged cartons.
- Be valued in excess of $250.00 net.
- Shipped and invoiced within the previous 120 days.
- Can't be custom, non-cataloged goods, master-keyed or ACCENTRA Quick Ship Product or 10B Finished products. A MINIMUM reprocessing fee of 45% will be charged. Upon receipt and verification by ACCENTRA that the returned merchandise meets the foregoing conditions, a credit will be issued for the original invoice amount less the MINIMUM 45% reprocessing fee. "Goodwill" products that meet the foregoing criteria may be returned by fulfilling the following conditions:
- Send an RGA request in writing to the ACCENTRA Sales Representative serving the Purchaser's area.
- Ensure the RGA labels that are sent to Purchaser by ACCENTRA are visible on return goods shipment.
- Ensure that the RGA number appears on the return shipment label and is legible.
- Return the authorized merchandise within sixty (60) days from the date of RGA issuance date.
- Return shipments must be freight prepaid to the location specified on the RGA. ACCENTRA is not liable for damages to product during shipping. No credit may be taken or issued prior to RGA approval and receipt of product.
All defective goods within the terms of our limited warranty may be returned for credit or replacement.
nexTouch® Cylindrical Locks
Distributor List Prices
| ANSI/BHMA CODE | FINISH DESCRIPTION | ANSI/BHMA CODE | FINISH DESCRIPTION | ||
|---|---|---|---|---|---|
| BRASS: | CHROME: | ||||
| 605 | Bright Brass, Clear Coated | 626 | Satin Chrome Plated | ||
| BRONZE: | PAINTED: | ||||
| 613E | Dark Oxidized Satin Bronze - equivalent | BSP | Black Suede Powder Coat | ||
| KEYING CHARGES | DEDUCT | ADD | |||
|
Masterkeying, Grand Masterkeying, Great Grand Masterkeying
(all cylinders except security cylinders and IC cores) |
$16.00 | ||||
| Cylinder or Lock Operated by Two or More Keys Not MK or GMK | $16.00 | ||||
| Customer Bittings and Sample Keys | $16.00 | ||||
| Schlage C Keyed Alike (KA) keying charge | $16.00 | ||||
| PRODUCT OPTIONS | DEDUCT | ADD | |||
| CYLINDERS: 6-Pin Only | |||||
| LESS CYLINDER OR LESS CORE: | |||||
| Standard cylinder prep less cylinder, specify "x LC" Ordering Example: AU-NTB613 x LC | $90.00 | — | |||
|
Large format interchangeable core prep less core, for 6-pin, specify "x 1210 Prep x Less Core"
Ordering Example: AU-NTB613 x 1210 Prep Less Core |
— | $0.00 | |||
| INTERCHANGEABLE CORE CYLINDERS: | |||||
| 1210 - LFIC 6-Pin (includes MK or GMK) Ordering Example: AU-NTB613 x 1210 x 626 | — | $83.00 | |||
| A600 Best Keyway SFIC 6- or 7-Pin (includes MK or GMK) Ordering Example: B-AU-NTB613 x A600 | — | $73.00 | |||
| CYLINDERS OPTIONS: | |||||
| Ordering Example: B-AU-NTB613 x Less Core | Lockset with SFIC Core Prep (less core) Prefix B to trim designation. Specify 6 or 7-Pin. | $0.00 | $0.00 | ||
|
Lockset with Medeco®/ASSA® IC Core Prep (less core) Prefix M to trim designation. Not available with MO or PB levers.
6-Pin only. Ordering Example: M-AU-NTB613 x Less Core |
$0.00 | $0.00 | |||
| Ordering Example: SI-AU-NTB613 x Less Core | Lockset with Schlage® IC Core Prep (less core) Prefix SI to trim designation. Not available with MO levers. 6-pin only. | $0.00 | $0.00 | ||
|
Lockset with Corbin Russwin IC Core Prep (less core) Prefix R to trim designation. Not available with MO or PB levers.
6-pin only. Ordering Example: R-AU-NTB613 x Less Core |
$0.00 | $0.00 | |||
| Ordering Example: SG-AU-NTB613 x Less Core | Lockset with Sargent IC Core Prep (less core) Prefix SG to trim designation. Not available with MO levers. 6-pin only. | $0.00 | $48.00 | ||
| Ordering Example: S-AU-NTB613 x Less Cylinder | Lockset with Schlage® Standard Cylinder Prep (less cylinder) Prefix S to trim designation. 6-pin only. | $36.00 | $0.00 | ||
|
Lockset with Schlage® "C" Keyway Cylinder (specify cylinder model number 2803-53L)
Ordering Example: AU-NTB613 x 2803-53L x 626 |
$0.00 | $0.00 | |||
| Ordering Example: AU-NTB613 x 100CV1 x 626 | Lockset with Arrow "AR" Keyway Cylinder (specify cylinder model 100CV1) | $0.00 | $0.00 | ||
|
Lockset with Corbin Russwin "L4", Corbin "60", Russwin "D1", Sargent® "LA" or Schlage® "E" Keyway Cylinder. (specify
cylinder model number 3803-53L x keyway) Ordering Example: AU-NTB613 x 3803-53L-LA x 626 |
$0.00 | $23.00 | |||
| KNURLING: Available for all levers in 613E and 626 finishes only | |||||
| Outside (KNO) or Inside (KNI) Only | — | $109.00 | |||
| Both Sides (KNB) | — | $218.00 | |||
| ABRASIVE COATING: | |||||
| Outside (ABCO) or Inside (ABCI) Only | — | $67.00 | |||
| Both Sides (ABCB) | — | $134.00 | |||
| DOOR THICKNESS: 1-3/4" (For 1-3/8" thick doors, thin door kit must be used) | — | STD |
NOTE: SECURITY & ACCENTRA KEYMARK® CYLINDERS: These cylinders are priced and discounted separately.
nexTouch® Cylindrical Locks
Distributor List Prices
LEVER DESIGNS: Augusta-AU Monroe - MO Pacific Beach - PB Reflections® - TB, UB
| MODEL # | PRODUCT DESCRIPTION | 605 613E 626 BSP* |
|---|---|---|
| ACCENTRA NEXTOUCH® MOBILE CAPABLE CYLINDRICAL LOCKS (ACCENTRA MODULE INCLUDED) | ||
| NTB613-ACC | Cylindrical Lock w/Pushbutton Keypad - Key Override | $995.00 |
| NTB633-ACC | Cylindrical Lock w/Pushbutton Keypad - No Key Override | $905.00 |
| NTB623-ACC | Cylindrical Lock w/Capacitive Touchscreen - Key Override | $1,024.00 |
| NTB643-ACC | Cylindrical Lock w/Capacitive Touchscreen - No Key Override | $934.00 |
* Contact local sales representative for split finish options
| MODEL # | PRODUCT DESCRIPTION | ORDERED SEPARATELY | ORDERED WITH LOCKSET |
|---|---|---|---|
| STRIKES: | |||
| 202 | Strike Box (Not Plated) | $2.00 | $2.00 |
| 371 | Strike 1 1/4" Lip with Box | $11.00 | N/C |
| 371 | Strike 1", 1-1/2", 1-3/4" or 2" Lip with Box | $22.00 | $2.00 |
| 497 | ANSI Strike Lip 1-1/4" | $54.00 | STD |
| 497 | ANSI Strike with 1-1/8", 1-1/2" or 1-3/4" Lip | $61.00 | $18.00 |
| DEADLOCKING LATCHBOLTS: | |||
| E694 | Beveled, 2-3/4" Backset, 1/2" Throw, 2-1/4" x 1-1/8" Front | $132.00 | STD |
| F694 | Flat, 2-3/4" Backset, 1/2" Throw, 2-1/4" x 1-1/8" Front | $132.00 | N/C |
| 480B | Beveled, 2-3/4" Backset, 3/4" Throw, 2-1/4" x 1-1/8" Front | $252.00 | $120.00 |
| F480B | Flat, 2-3/4" Backset, 3/4" Throw, 2-1/4" x 1-1/8" Front | $252.00 | $120.00 |
| 380N | 2-3/8" Backset, 2-1/4" x 1" Front | $50.00 | N/C |
| MODEL # | PRODUCT DESCRIPTION | ORDERED SEPARATELY | ORDERED WITH LOCKSET | ||
|---|---|---|---|---|---|
| CYLINDERS: | |||||
| 1803-53L | Standard Cylinder 6-Pin | $90.00 | N/C | ||
| 5803-53L | Security Cylinder 6-Pin | $359.00 | $269.00 | ||
| K800 | ACCENTRAKeyMark® Large Format Interchangeable Core Only 6-Pin | $121.00 | $121.00 | ||
| K403-53L | ACCENTRA KeyMark® Cylinder | $113.00 | $113.00 | ||
| 1210 | Large Format Interchangeable Core Only 6-Pin | $83.00 | $83.00 | ||
| 5210 | Security Large Format Interchangeable Core Only 6-Pin | $330.00 | $330.00 | ||
| K600 | ACCENTRA KeyMark Small Format Interchangeable Core | $115.00 | $115.00 | ||
| 2803-53L | Schlage "C" Keyway Cylinder 6-Pin - 0bitted or Keyed Random | $90.00 | N/C | ||
| 3803-53L | Other Manuf. Keyway Cylinder 6-Pin - Keyed Random, Specify Keyway | $113.00 | $23.00 | ||
| 100CV1 | Arrow "AR" Keyway Cylinder | $90.00 | N/C | ||
| A600 | Small Format Core Only, 6- or 7-Pin | $73.00 | $73.00 | ||
| 108S | Schlage® Cylinder Adapter Kit | $27.00 | $27.00 | ||
nexTouch ACCENTRA lock part numbers NTB613, NTB623, NTB633, & NTB643 can be used as a stand alone, keypad only function by removing the ACCENTRA radio module from the lock. These part numbers can NOT be upgraded to and are not warranted for use with a Z-Wave, Zigbee, or other WiFi compatible system.
nexTouch® Cylindrical Locks
Distributor List Prices
| PARTS | ||||||
|---|---|---|---|---|---|---|
| LEVERS ONLY: | PART NUMBER | PART NUMBER | PART NUMBER | PART NUMBER | PART NUMBER | 605 613E |
| AU | MO | PB | TB | UB | 626 BSP | |
| Plain Inside (for use with | 14-YM00-6040 x | 14-5301-6902 x | 14-5301-6054 x | 14-5301-6201 x | 14-5301-6301 x | $84.00 |
| NTB600) | Finish | Finish | Finish | Finish | Finish | |
| Plain Outside (for use with | 14-YM00-6060 x | 14-5303-6066 x | 14-5303-6062 x | 14-5303-6203 x | 14-5303-6303 x | $84.00 |
| NTB633/643) | Finish | Finish | Finish | Finish | Finish | |
| Standard Cylinder Outside (for | 14-YM00-6039 x | 14-5305-6056 x | 14-5305-6054 x | 14-5300-6200 x | 14-5300-6300 x | $84.00 |
| use with NTB613/623) | Finish | Finish | Finish | Finish | Finish | |
| SFIC Outside (for use with | 14-YM00-6030 x | 14-5305-0016 x | 14-5305-0012 x | 14-5305-6206 x | 14-5305-6306 x | $104.00 |
| NTB613/623) | Finish | Finish | Finish | Finish | Finish | |
| LFIC Outside (for use with | 14-YM00-6028 x | 14-5305-6059 x | 14-5305-6051 x | 14-5305-6205 x | 14-5305-6305 x | $104.00 |
| NTB613/623) | Finish | Finish | Finish | Finish | Finish | |
| OTHER COMPONENTS: | PART NUMBER | NO FINISH | ||||
| Motorized Lock Chassis (1-3/8" & 1-3/4" door) | 14-5361-0902-048 | $167.00 | ||||
| Battery Cover | 14-B600-0200-999 | $53.00 | ||||
| MODEL/PART # | PRODUCT DESCRIPTION | LIST PRICE |
|---|---|---|
| nexTouch® ACCESSORIES: | ||
| 784 | Optional remote 9VDC power supply with plug-in wall transformer | $755.00 |
| WH-28 | Remote power and request to enter wire harness | $97.00 |
| 14-4761-0106-025 |
1-3/8" Thin door kit. Includes inside and outside escutcheon spacers as well as a
2-3/8" latchbolt |
$109.00 |
| 14-B600-0111-999 | 3-Wire Door Position Sensor | $45.00 |
| PART # |
PRODUCT DESCRIPTION
LIST PRICE |
||
|---|---|---|---|
| DATA-ON-CARD MODULE | |||
| NTX600-ACC-Key | ACCENTRA module | $172.00 | |
Distributor List Prices
| ANSI/BHMA CODE | FINISH DESCRIPTION | PART DESIGNATION |
|---|---|---|
| BRASS: | ||
| 605 | Bright Brass, Clear Coated | 003 |
| BRONZE: | ||
| 613E | Dark Oxidized Satin Bronze - equivalent | 13E |
| CHROME: | ||
| 626 | Satin Chrome Plated | 025 |
| PAINTED: | ||
| BSP | Black Suede Powder Coat | BSP |
| KEYING CHARGES | DEDUCT | ADD |
|---|---|---|
|
Masterkeying, Grand Masterkeying, Great Grand Masterkeying
(all cylinders except security cylinders and IC cores) |
$16.00 | |
| Cylinder or Lock Operated by Two or More Keys Not MK or GMK | $16.00 | |
| Customer Bittings and Sample Keys | $16.00 | |
| Schlage C Keyed Alike (KA) keying charge | $16.00 | |
| PRODUCT OPTIONS | DEDUCT | ADD |
|---|---|---|
| LESS CYLINDER: Specify "x LC" | $104.00 | — |
| Cylinder rings/collars not furnished with locksets ordered less cylinders. | ||
| IC Housing ordered with locksets (ICLC) | — | $0.00 |
| 7-PIN CYLINDERS: Add to 6-Pin cylinder | — | $2.00 |
| DUST GUARD: Prefix "D" to model number (refer to catalog for available cylinders) | — | $69.00 |
| INTERCHANGEABLE CORE CYLINDERS: | ||
|
2196 - LFIC 6-Pin (Includes MK or GMK)
Ordering Example: NTM613-ACC x 2196 x LH x 626 |
— | $83.00 |
|
A620 - SFIC 6-or 7-Pin (Includes MK or GMK)
Ordering Example: NTM613-ACC x A620 x RH x 626 |
— | $73.00 |
| TORX® SECURITY HEAD SCREWS: | ||
| Standard size only (add for each screw) | — | $1.00 |
| Quantity Required: Sectional Trim = 4 | — | $4.00 |
| SPECIAL STRIKES: | ||
| Strikes with lip lengths other than 1-1/8" or 1-1/4" | — | $18.00 |
| KNURLING: Available for all knob and levers in any finish except HA, PN and all Reflections® levers | ||
| Outside (KNO) or Inside (KNI) Only | — | $109.00 |
| Both Sides (KNB) | — | $218.00 |
| ABRASIVE COATING: Lever | ||
| Outside (ABCO) or Inside (ABCI) Only | — | $67.00 |
| Both Sides (ABCB) | — | $134.00 |
| DOORS 1-3/4" THICK TO 2-1/4" THICK: With lock centered in the door. Special product application request required for locks not centered in door. | ||
| Non-keyed | — | $149.00 |
| Single cylinder keyed | — | $236.00 |
| Double cylinder keyed | — | $264.00 |
Distributor List Prices
LEVER DESIGNS: Arcadia - AR* Augusta-AU Carmel - CR Jefferson - JN* Monroe - MO Pacific Beach - PB Pinehurst - PN* Virginia - VI*
REFLECTIONS DESIGNS: Hudson: TB*, TC*, UB*, UC*, TD*
Danube: TE*, TI* Seine: TG*, TJ*, TK*
Thames: TM*, TN*, TP*, TQ*, TR*, TS* Victoria: TT*, TU*, TW*, TY*, TX*, UX*
Niagara: MA*, RA*, RB*, RC*
ROSE DESIGNS: R3, R4, R5, R6, R7, R8, R9
Copenhagen - R
*These designs will incur the $158.00 price adder as established in the standard mortise locks. This includes all reflections trim.
| MODEL # | PRODUCT DESCRIPTION | 605 613E 626 BSP* | |
|---|---|---|---|
| ACCENTRA NE | ACCENTRA NEXTOUCH® MOBILE CAPABLE MORTISE LOCKS (ACCENTRA MODULE INCLUDED) | ||
| NTM613-ACC | Mortise Lock w/Pushbutton Keypad - Key Override - No Deadbolt | $1,320.00 | |
| NTM618-ACC | Mortise Lock w/Pushbutton Keypad - Key Override - w/Deadbolt | $1,345.00 | |
| NTM633-ACC | Mortise Lock w/Pushbutton Keypad - No Key Override - No Deadbolt | $1,216.00 | |
| NTM638-ACC | Mortise Lock w/Pushbutton Keypad - No Key Override - w/Deadbolt | $1,241.00 | |
| NTM623-ACC | Mortise Lock w/Capacitive Touchscreen - Key Override - No Deadbolt | $1,349.00 | |
| NTM628-ACC | Mortise Lock w/Capacitive Touchscreen - Key Override - w/Deadbolt | $1,374.00 | |
| NTM643-ACC | Mortise Lock w/Capacitive Touchscreen - No Key Override - No Deadbolt | $1,245.00 | |
| NTM648-ACC | Mortise Lock w/Capacitive Touchscreen - No Key Override - w/Deadbolt | $1,270.00 | |
* Contact local sales representative for split finish options
| MODEL # | PRODUCT DESCRIPTION | 605 613E 626 BSP |
|---|---|---|
| STRIKES: | ||
| 2815 | Latchbolt and Deadbolt , Curved Lip (8800) | $54.00 |
| 2816 | Latchbolt and Deadbolt , Flat Lip (8800) | $54.00 |
nexTouch ACCENTRA lock part numbers NTM613, NTM618, NTM623, NTM628, NTM633, NTM638, NTM643, & NTM648 can be used as a stand alone, keypad only function by removing the Accentra radio module from the lock. These part numbers can NOT be upgraded to and are not warranted for use with a Z-Wave, Zigbee, or other WiFi compatible system.
Distributor List Prices
Mortise Motorized Lock Body
| PART NUMBER | DESCRIPTION | LIST PRICE |
|---|---|---|
| 50-M600-0100-014 | Lockbody No Deadbolt | $448.00 |
| 50-M605-0100-014 | Lockbody w/Deadbolt | $594.00 |
Fixed Core Mortise Cylinders
| MODEL # | PRODUCT DESCRIPTION |
ORDERED
SEPARATELY |
|||
|---|---|---|---|---|---|
| 2153 |
Standard Cylinder for 8800FL, 8800, 8800RL, 350 Series Deadlocks
1" - 1-3/4" |
2160 | $104.00 | ||
| 2123 |
Extra Length Cylinder for 8800FL, 8800, 8800RL
1-7/8" - 3-1/2" |
2160 | $144.00 | ||
| 2553 | Schlage® "C" Keyway Cylinder 6-Pin - 0-bitted or Keyed Random | 1-1/8" | 2160 | $104.00 | |
| 7-Pin | Cylinders | ADD | –– | — | $2.00 |
Interchangeable Core Mortise Cylinders: LFIC
| MODEL # | PRODUCT DESCRIPTION | LENGTH | CAM | ALL FINISHES |
|---|---|---|---|---|
| MORTISE | ||||
| 2196 | LFIC Cylinder 6-Pin | 1-1/2", 1-3/4", 2" | 2160 | $187.00 |
| 2197 | LFIC Cylinder 7-Pin | 1-11/16", 2" | 2160 | $189.00 |
Security Cylinders
| MODEL # | PRODUCT DESCRIPTION | CAM | ORDERED SEPARATELY |
ORDERED WITH
LOCKSET ADD |
|---|---|---|---|---|
| MORTISE | ||||
| 5153 | Security Cylinder 6-Pin | 2160 | $409.00 | $305.00 |
| 5153 | Security Cylinder 7-Pin | 2160 | $413.00 | $309.00 |
U.L. High Security Cylinders
| MODEL # | PRODUCT DESCRIPTION | CAM | ORDERED SEPARATELY |
ORDERED WITH
LOCKSET ADD |
|---|---|---|---|---|
| MORTISE | ||||
| U5153 | High Security Cylinder 6-Pin | 2160 | $547.00 | $443.00 |
| U5153 | High Security Cylinder 7-Pin | 2160 | $551.00 | $447.00 |
Distributor List Prices
Security Interchangeable Core Mortise Cylinders
| MODEL # | PRODUCT DESCRIPTION | CAM | ORDERED SEPARATELY |
ORDERED WITH
LOCKSET ADD |
|---|---|---|---|---|
| MORTISE | ||||
| 5196 | LFIC Security Cylinder 6-Pin | 2160 | $506.00 | $402.00 |
| 5197 | LFIC Security Cylinder 7-Pin | 2160 | $510.00 | $406.00 |
Complete Cylinders: SFIC
Note: A620 include Best® keyway core (A600), specify keyway.
| MODEL # | PRODUCT DESCRIPTION | CAM | 606 626 |
|---|---|---|---|
| MORTISE | |||
| A620 | SFIC Cylinder 6- or 7-Pin | KC1 | $177.00 |
ACCENTRA KeyMark® Cylinders, Cores And Housings
MORTISE CYLINDERS:
| MODEL # | PRODUCT DESCRIPTION | LENGTHS | ALL FINISHES |
|---|---|---|---|
| K100 | Fixed Core Mortise Cylinder | 1-1/8", 1-1/4" | $121.00 |
| K100 | Fixed Core Mortise Cylinder | 1-1/2", 1-3/4", 2" | $257.00 |
| K620 | SFIC Mortise Cylinder | 1-1/4", 1-3/8", 1-3/4" | $219.00 |
| K630 | SFIC Tapered Mortise Cylinder | 1-1/4", 1-3/8" | $222.00 |
| K820 | LFIC Mortise Cylinder | 1-1/2", 1-11/16", 1-3/4", 2" | $225.00 |
MORTISE CORES:
| MODEL # | PRODUCT DESCRIPTION | 606 626 |
|---|---|---|
| K600 | SFIC Core | $115.00 |
| K800 | LFIC Core | $121.00 |
| K890 | LFIC Core for Schlage | $121.00 |
MORTISE HOUSINGS:
| MODEL # | PRODUCT DESCRIPTION | LENGTHS | ALL FINISHES |
|---|---|---|---|
| K660 | SFIC Mortise Housing | 1-1/4", 1-3/8",1-3/4" | $104.00 |
| K670 | SFIC Tapered Mortise Housing | 1-1/4", 1-3/8" | $107.00 |
| K860 | LFIC Mortise Housing | 1-1/2", 1-11/16", 1-3/4", 2" | $104.00 |
When Ordering: Specify finish.
Specify ring/collar size when ordering with cylinder.
Distributor List Prices
Cylinder Components & Options
| MODEL # | PRODUCT DESCRIPTION | ALL FINISHES |
|---|---|---|
| KP3 | Wave Washer | $5.80 |
| Cylinder Ring .062"219" | ||
| 1765 | Cylinder Ring .250"656" | $49.20 |
| 1766 | Tubular Spacer Collar for Mortise and Rim High Security | $70.30 |
* Specify dimension. Cylinder rings not furnished with locksets or other products when ordered less cylinders. When cylinders ordered separately, ring length must be specified.
| MODEL/PART # | PRODUCT DESCRIPTION | LIST PRICE |
|---|---|---|
| SECTIONAL MORTISE SCAR PLATE KITS (includes 1 o/s plate & 1 i/s plate): | ||
| 50-M600-0150-033 | O/S with cylinder - I/S no thumbturn | |
| 50-M600-0151-033 | O/S no cylinder - I/S no thumbturn | |
| 50-M600-0152-033 | O/S with cylinder - I/S with thumbturn | $129.00 |
| 50-M600-0153-033 | O/S no cylinder - I/S with thumbturn |
| MODEL/PART # | PRODUCT DESCRIPTION | LIST PRICE |
|---|---|---|
| ACCESSORIES: | ||
| 784 | Optional remote 9VDC power supply with plug-in wall transformer | $755.00 |
| WH-28 | Remote power and request to enter wire harness | $97.00 |
| PART # | PRODUCT DESCRIPTION | LIST PRICE |
|---|---|---|
| DATA-ON-CARD MODULE | ||
| NTX600-ACC-Key | ACCENTRA module | $172.00 |
Distributor List Prices
|
ANSI/BHMA
CODE |
FINISH DESCRIPTION | PART DESIGNATION |
|---|---|---|
| BRASS: | ||
| 605 | Bright Brass, Clear Coated | 003 |
| BRONZE: | ||
| 613E | Dark Oxidized Satin Bronze - equivalent | 13E |
| CHROME: | ||
| 626 | Satin Chrome Plated | 025 |
| PAINTED: | ||
| BSP | Black Suede Powder Coat | BSP |
| KEYING CHARGES | DEDUCT | ADD |
|---|---|---|
| Masterkeying, Grand Masterkeying, Great Grand Masterkeying (all cylinders except security cylinders and IC cores) | _ | $16.00 |
| Cylinder or Lock Operated by Two or More Keys Not MK or GMK | _ | $16.00 |
| Customer Bittings and Sample Keys | _ | $16.00 |
| Schlage C Keyed Alike (KA) keying charge | _ | $16.00 |
| PRODUCT OPTIONS | DEDUCT | ADD |
|---|---|---|
| LESS CYLINDER: Specify "x LC" Cylinder rings/collars not furnished with locksets ordered less cylinders. | $104.00 | _ |
| IC Housing ordered with locksets (ICLC) | _ | $0.00 |
| 7-PIN CYLINDERS: Add to 6-Pin cylinder | _ | $2.00 |
| DUST GUARD: Prefix "D" to model number (refer to catalog for available cylinders) | _ | $69.00 |
| INTERCHANGEABLE CORE CYLINDERS: | ||
| 2196 - LFIC 6-Pin (Includes MK or GMK) Ordering Example: NTT613-ACC x 2196 x LHR x 626 | _ | $83.00 |
| A620 - SFIC 6-or 7-Pin (Includes MK or GMK) Ordering Example: NTT613-ACC x A620 x RHR x 626 | _ | $73.00 |
| TORX® SECURITY HEAD SCREWS: Standard size only (add for each screw) | _ | $1.00 |
| Quantity Required: Sectional Trim = 4 | _ | $4.00 |
NOTE: Split finishes are not available for the nexTouch® locks.
Distributor List Prices
NEXTOUCH® MOBILE CAPABLE EXIT TRIM (ACCENTRA MODULE INCLUDED)
DESIGNS: Augusta-AU Monroe - MO Pacific Beach - PB
| MODEL # | PRODUCT DESCRIPTION |
ALL
FINISHES |
|---|---|---|
| NTT613-ACC | Exit Rim Trim w/Pushbutton Keypad - Key Override | $1,265.00 |
| NTT623-ACC | Exit Rim Trim w/Capacitive Touchscreen - Key Override | $1,294.00 |
| MODEL # | PRODUCT DESCRIPTION | ALL FINISHES |
|---|---|---|
| 2153 | Standard Cylinder for 8800FL, 8800, 8800RL, 350 Series Deadlocks | $104.00 |
| 2553 |
Schlage®
"C" Keyway Cylinder 6-Pin - 0-bitted or Keyed Random |
$104.00 |
| 7PIN | 7 Pin Adder | $2.00 |
Interchangeable Core Mortise Cylinders: LFIC
| MODEL # | PRODUCT DESCRIPTION | LENGTH | CAM | ALL FINISHES |
|---|---|---|---|---|
| MORTISE | ||||
| 2196 | LFIC Cylinder 6-Pin | 1-1/2", 1-3/4", 2" | 2160 | $187.00 |
| 2197 | LFIC Cylinder 7-Pin | 1-11/16", 2" | 2160 | $189.00 |
nexTouch ACCENTRA lock part numbers NTT613 & NTT623 can be used as a stand alone, keypad only function by removing the Accentra radio module from the lock. These part numbers can NOT be upgraded to and are not warranted for use with a Z-Wave, Zigbee, or other WiFi compatible system.
Distributor List Prices
Security Interchangeable Core Mortise Cylinders
| MODEL # | PRODUCT DESCRIPTION | CAM |
ORDERED
SEPARATELY |
ORDERED WITH LOCKSET
ADD |
|---|---|---|---|---|
| SECURITY CYLINDERS | ||||
| 5153 | Security Cylinder 6-Pin | $409.00 | $305.00 | |
| MORTISE | ||||
| 5196 | LFIC Security Cylinder 6-Pin | 2160 | $506.00 | $402.00 |
| 5197 | LFIC Security Cylinder 7-Pin | 2160 | $510.00 | $406.00 |
Complete Cylinders: SFIC
Note: A620 include Best® keyway core (A600), specify keyway.
| MODEL # | PRODUCT DESCRIPTION | CAM | ALL FINISHES |
|---|---|---|---|
| MORTISE | |||
| A620 | SFIC Cylinder 6- or 7-Pin | KC1 | $177.00 |
ACCENTRA KeyMark® Cylinders, Cores And Housings
MORTISE CYLINDERS:
| MODEL # | PRODUCT DESCRIPTION | LENGTHS | ALL FINISHES |
|---|---|---|---|
| K100 | Fixed Core Mortise Cylinder | 1-1/8", 1-1/4" | $121.00 |
| K620 | SFIC Mortise Cylinder | 1-1/4", 1-3/8", 1-3/4" | $219.00 |
| K820 | LFIC Mortise Cylinder | 1-1/2", 1-11/16", 1-3/4", 2" | $225.00 |
MORTISE HOUSINGS:
| MODEL# | PRODUCT DESCRIPTION | LENGTHS | ALL FINISHES |
|---|---|---|---|
| K660 | SFIC Mortise Housing | 1-1/4", 1-3/8",1-3/4" | $104.00 |
| K670 | SFIC Tapered Mortise Housing | 1-1/4", 1-3/8" | $107.00 |
When Ordering: Specify finish.
Specify ring/collar size when ordering with cylinder.
Distributor List Prices
Cylinder Components & Options
| MODEL # | PRODUCT DESCRIPTION | ALL FINISHES |
|---|---|---|
| KP3 | Wave Washer | $5.80 |
| Cylinder Ring .062"219" | ||
| 1765 | Cylinder Ring .250"656" | $49.20 |
| 1766 | Tubular Spacer Collar for Mortise and Rim High Security | $70.30 |
* Specify dimension. Cylinder rings not furnished with locksets or other products when ordered less cylinders. When cylinders ordered separately, ring length must be specified.
| MODEL/PART # | PRODUCT DESCRIPTION | LIST PRICE |
|---|---|---|
| ACCESSORIES: | ||
| 784 | Optional remote 9VDC power supply with plug-in wall transformer | $755.00 |
| WH-28 | Remote power and request to enter wire harness | $97.00 |
| 14-B600-0111-999 | 3-Wire Door Position Sensor | $45.00 |
| PART # | LIST PRICE | |
|---|---|---|
| DATA-ON-CARD MODULE | ||
| NTX600-ACC-Key | ACCENTRA module | $172.00 |
| MODEL/PART # | PRODUCT DESCRIPTION |
LIST PRICE
613E 605 630 BSP |
|---|---|---|
| ACCENTRA EXIT DEVICES: | ||
| 2100F | Fire Rated Rim | $1,095.00 |
| 6100F | Fire Rated Rim | $1,549.00 |
| 6150F | Fire Rated Squarebolt | $1,632.00 |
| 7100F | Fire Rated Rim | $2,376.00 |
| 7150F(WS) | Fire Rated Squarebolt Windstorm Certified | $2,617.00 |
How to order example: 7100F-36 626 LHR (Left Hand Reverse)
Notes:
- Specify finish 2100F is not available in 605 finish.
- Specify hand for all exits ordered (LHR/RHR).
- Specify DOW = Door Opening Width (-36 or -48, $70.00 add for 48")
nexTouch® Touchscreen Deadbolts
Distributor List Prices
nexTouch® Touchscreen Deadbolt
| ANSI/BHMA CODE | FINISH DESCRIPTION |
PART NUMBER
FINISH DESIGNATION |
|---|---|---|
| BRONZE: | ||
| US10BP | Oil Rubbed Bronze - Permanent | 0BP |
| NICKEL: | ||
| 619 | Satin Nickel Plated, Clear Coated | 619 |
| PAINTED: | ||
| BSP | Black Suede Powder Coat | BSP |
| PRODUCT OPTIONS | DEDUCT | ADD |
|---|---|---|
| CYLINDERS: 5 & 6-Pin Only | ||
| Standard Cylinder - Kwikset, available KA, KD (std), MK | — | — |
| Optional Cylinder - PARA, available 0-bitted, KD KA, MK | — | — |
| Optional Cylinder - Schlage C - available KA, KD, MK | — | — |
| INTERCHANGEABLE CORE CYLINDERS: | ||
| Lock SFICLC only and will include small format interchangeable core housing only.* | — | — |
| THIN DOOR KIT: | ||
| Part Number: AYRDT226-TS-GSK (for doors 1-3/8" to 1-3/4" thick) | — | $4.00 |
* A600 or K600 SFICs available through ASSA ABLOY ACCENTRA™ and should be listed as separate line item.
SFIC HOUSINGS:
| MODEL # | PRODUCT DESCRIPTION | 619 BSP OBP |
|---|---|---|
| 14-D600-6005-FIN | SFIC cylinder housing only | $27.00 |
Note: If SFIC cylinder housing is required, order separate line item for the SFIC cylinder housing as an accessory. SFIC cylinder housing will ship separately and will need to be field installed.
| MODEL # | PRODUCT DESCRIPTION | 619 0BP BSP | |
|---|---|---|---|
| nexTouch® MOBILE CAPABLE DEADBOLT LOCK | |||
| NTD623-ACC | nexTouch® Deadbolt - Key Override | ||
| NTD643-ACC | nexTouch® Deadbolt - Key Free | $564.00 | |
Note: LFIC is not available for nexTouch® electronic locks
nexTouch® Touchscreen Deadbolt
Distributor List Prices
| MODEL # | PRODUCT DESCRIPTION |
ORDERED SEPARATELY
619 0BP |
ORDERED WITH LOCK
SET |
|---|---|---|---|
| STRIKES: | |||
| 498* | Standard Deadbolt Strike/Round Corner | STD | |
| 499* | Standard Deadbolt Strike/Square Corner | $2.10 | N/C |
| LATCHBOLTS: | |||
| 698R* | Standard Radius Corner Adjustable Deadbolt Latch | STD | |
| 699A* | Standard Square Corner Adjustable Deadbolt Latch | $15.50 | $15.50 |
| MODEL # | PRODUCT DESCRIPTION |
ORDERED SEPARATELY
619 BSP |
ORDERED WITH LOCK
SET |
|---|---|---|---|
| CYLINDERS: | |||
| 3809-178S** | Kwikset Standard cylinder 5-Pin KD | STD | |
| 1809-178S* | PARA optional cylinder kit. Available in 0-bitted and KD* | $14.70 | N/C |
| 2809-178S** | Schlage C cylinder Available KD | N/C |
NET KEYING CHARGES: KA Keyed-alike $1.00 $1.00 MK Master Keyed $3.00 $3.00
Kwikset and Schlage C Cylinders also available MK. *Specify finish when ordering.
| LATCH & STRIKE FINISHES: | ||
|---|---|---|
| Lock Finish | Specify | |
| 619 | 025 | |
| BSP | BSP | |
| 10BP | BSP | |
| CYLINDER FINISHES: | |
|---|---|
| Lock Finish | Specify |
| 619 | 626 |
| BSP | BSP |
| 10BP | BSP |
** Specify keying and finish
nexTouch® Touchscreen Interconnected Lock
Distributor List Prices
| ANSI/BHMA CODE | FINISH DESCRIPTION |
PART NUMBER
FINISH DESIGNATION |
|---|---|---|
| BRONZE: | ||
| US10BP | Oil Rubbed Bronze - Permanent | 0BP |
| NICKEL: | ||
| 619 | Satin Nickel Plated, Clear Coated | 619 |
| PAINTED: | ||
| BSP | Black Suede Powder Coat | BSP |
Split Finish Option Exterior Finish /Interior Finish - Add $65 USD
| PRODUCT OPTIONS | DEDUCT | ADD | |
|---|---|---|---|
| CYLINDERS: 5 & 6-Pin Only | |||
| Standard Cylinder - Kwikset, available KA, KD (std), MK | — | — | |
| Optional Cylinder - PARA, available 0-bitted, KD KA, MK | — | — | |
| Optional Cylinder - Schlage C - available KA, KD, MK | — | — | |
| INTERCHANGEABLE CORE CYLINDERS: | |||
| Lock SFICLC only and will include small format interchangeable core housing only.* | — | — | |
Note: LFIC is not available for nexTouch® electronic locks
* A600 or K600 SFICs available through ASSA ABLOY ACCENTRA™ and should be listed as separate line item.
nexTouch® Touchscreen Interconnected Lock
Distributor List Prices
LEVER DESIGNS: Augusta AU Delaware DW Monroe MO Norwood NW
Pacific Beach PB Valdosta VL
| MODEL # | PRODUCT DESCRIPTION | 619 0BP BSP | |
|---|---|---|---|
| nexTouch® MOBILE CAPABLE TOUCHSCREEN INTERCONNECT LOCK | |||
| NTC623-ACC | nexTouch® Interconnect Lock - Key Override | ||
| NTC643-ACC | nexTouch® Interconnect Lock - Key Free | $751.00 | |
| MODEL # | PRODUCT DESCRIPTION |
ORDERED SEPARATELY
BSP 619 0BP |
ORDERED WITH LOCKSET |
| DBLT STRIKE: | |||
| 498* | Standard Deadbolt Strike/Round Corner | $2.10 | STD |
| ICL STRIKES: | |||
| YR02000* | Standard Full Lip Strike Radius Corner | STD | |
| YR02001* | Optional Full Lip Strike Square Corner | $2.10 | N/C |
| YR02020* | Optional T-Strike | $3.10 | $3.10 |
| YR02030* | Optional ANSI 4-7/8 Strike | $8.80 | $8.80 |
| DBLT LATCHBOLT: | |||
| 698R* |
Standard Radius Corner Adjustable Deadbolt
Latch |
STD | |
| 699A* |
Standard Square Corner Adjustable Deadbolt
Latch |
$15.50 | $15.50 |
^ Adjustable between 2-3/8" and 2-3/4"
* Specify finish
| MODEL # | PRODUCT DESCRIPTION |
ORDERED SEPARATELY
605 0BE 619 0BP |
ORDERED WITH LOCKSET |
|---|---|---|---|
| ICL LATCHBOLT: | |||
| YR01802*U | 2-3/8" BS Radius Corner Front | STD | |
| YR01804*U | 2-3/8" BS Square Corner Front | N/C | |
| YR01806*U | 2-3/4" BS Radius Corner Front |
$13.20
STD |
|
| YR01808*U | 2-3/4" BS Square Corner Front | N/C | |
* Specify finish when ordering: "6" - 619
"B" - 10BP
nexTouch® Touchscreen Interconnected Lock
Distributor List Prices
| MODEL # | PRODUCT DESCRIPTION | ORDERED SEPARATELY 26 | ORDERED WITH LOCKSET |
|---|---|---|---|
| CYLINDERS: | |||
| 3809-178S** | Kwikset cylinder 5-Pin KD | STD | |
| 1809-178S* | PARA optional cylinder kit. Available in 0-bitted and KD* | $14.70 | N/C |
| 2809-178S** | Schlage C cylinder Available KD | N/C |
SFIC HOUSINGS:
| MODEL # | PRODUCT DESCRIPTION | 619 BSP OBP |
|---|---|---|
| 14-D600-6005-FIN | SFIC cylinder housing only | $27.00 |
Note: If SFIC cylinder housing is required, order separate line item for the SFIC cylinder housing as an accessory. SFIC cylinder housing will ship separately and will need to be field installed.
| NET KEYING CHARGES: | |||
|---|---|---|---|
| KA | Keyed-alike | $1.00 | $1.00 |
| MK | Master Keyed | $3.00 | $3.00 |
Kwikset and Schlage C Cylinders also available MK.
Mounts For All Products
| PART # | DESCRIPTION | LIST PRICE | |
|---|---|---|---|
| Mounts Only | |||
| AYRD-MNT-YNT-CM | nexTouch® Cylindrical Mount | $412.00 | |
| 13-0202-0700-999 | nexTouch® Mortise Mount | ||
| AYRD-MNT | nexTouch® Deadbolt Mount | ||
| AYRD-MNT-YRC-CM | nexTouch® Accentra 4" Center to Center Interconnect Sample Mount - Right Hand | ||
| NTT612-ACC x MOUNT* | Exit Rim Trim w/Pushbutton Sample with Mount (specify trim and finish) | Add $412.00 to the List Price of the nexTouch® Trim Ordered for the Mount | |
| NTT622-ACC x MOUNT* | Exit Rim Trim w/Capacitive Touch Sample with Mount (specify trim and finish) | ||
* Ordering Example: NTT613-ACC x AU x 626 x MOUNT
* Specify finish
** Specify keying and finish
Notes
Distributor List Prices
Contact Us
| FOR QUESTIONS CONCERNING: | CONTACT: |
|---|---|
|
•
Troubleshooting • Product use and application (post training) • Technical product data • Part number lookup • Defective returns / RMA |
Technical Support Team
Phone: 800.810.WIRE (9473) Email: 800810WIRE@assaabloyusa.com |
|
•
Orders • Product Configuration/Part # • Order/RMA status • Book/List pricing • Lead-time |
Customer Support Team
Tel: 866-889-6242, select Option 2 Fax: 203-603-5981 Email: ESS.Orders@assaabloy.com |
TECHNICAL SUPPORT
(troubleshooting, product use and application, returns) Tel: 855-557-5078
Email: techsupport.accentra@assaabloy.com
CUSTOMER SUPPORT
(orders, product configuration, pricing, lead-time) Tel: 855-557-5078 x2
Email: Customerservice.Accentra@assaabloy.com
U.S.A.: ASSA ABLOY ACCENTRA™ 225 Episcopal Road, Berlin, CT 06037-4004 Tel: 1-800-438-1951 Fax: 1-800-338-0965 www.accentra-assaabloy.com
Canada: ASSA ABLOY Door Security Solutions Canada 160 Four Valley Drive Vaughan, Ontario L4K 4T9 Tel: 1-800-461-3007 Fax: 1-800-461-8989 assaabloydss.ca
International: ASSA ABLOY Americas International Tel: 1-905-821-7775 Fax: 1-905-821-1429 assaabloyai.com
